HIGH-QUALITY PLOUGHING WITHOUT COMPROMISE

HF Agro ploughs of the HF-111 series provide the highest quality ploughing in any soil conditions with maximum comfort for the tractor driver.

Maximum convenience, a huge selection of options and accessories, mechanical and hydraulic adjustments, reliable multi-stage protection - these are the HF Agro swing ploughs (and much more).



PROTECTION SYSTEMS

SHEAR BOLT PROTECTION

Bolt shearing force 3,000 kg

SPRING PROTECTION
Double protection: in all ploughs with this protection system, the tines are bolted to the beam, rather than welded. One of these mounting bolts is designed as a shear bolt, therefore, they function as an optional non-stop system.

HYDRAULIC PROTECTION
It allows the pressure to be adapted to the soil conditions. In heavy or compacted soil, the pressure can be increased to guarantee penetration and maintain optimal working position of the organs. On the contrary, in rocky conditions, the pressure can be set lower so that stones do not fall to the surface.
As with the spring loaded models, the tines are also bolted to the beam, rather than welded, to provide double protection.

COVERAGE MANUAL ADJUSTMENT
The coverage can be manually adjusted by simply repositioning the support bolt to a different hole in the beam.
There are 4 different working widths of 35 cm, 40 cm, 48 cm, 53 cm.

COVERAGE HYDRAULIC ADJUSTMENT
The coverage can be controlled hydraulically from the tractor cab from 30 to 50 cm per body.
Automatic memory system: HF Agro ploughs are supplied with an automatic memory system as a standard. The system extends the main frame to a minimum width to ensure smooth rolling and to avoid hitting the ground with the rear end of the plough.

The plough then automatically returns to the original working width.



SWING SEMI-MOUNTED PLOUGHS

ADVANTAGES

  • Ability to work in a track or in a furrow with the same plough.
  • Standard hydraulic 1st furrow adjustment.
  • Large 500/45 22.5” wheel as a standard.

  • WIDE RANGE OF PLOUGH SHARES
  • WIDE RANGE OF ACCESSORIES
  • HYDRAULIC WHEEL FOR DEPTH CONTROL
  • 3 TYPES OF PROTECTION
  • ON-LAND OPTIONS IN THE FURROW
  • STANDARD HYDRAULIC FITTING WIDTH ADJUSTMENT



SPECIFICATIONS

HF Agro ploughs are available with a different number of bodies (from 5 to 8), while ploughs can be equipped with additional tine bodies.

Each version of the HF Agro ploughs can be supplied with mechanical or hydraulic width adjustment, and with any of three types of protection.

Width adjustment Mechanics     Hydraulics
Working width, m 35, 40, 48, 53 30-53
Protection     Shear bolt or spring or hydraulics
Distance between
tools, cm
105
Clearance under the beam, cm 72, 78, или 90
Frame, mm 150x150
Rear wheel 500/45 22,5” hydraulics
Front wheel only in ON-LAND version: 250/65 14.5” 12 pr
1st furrow adjustment Hydraulics (standard)
